Sharon Particle Boards are produced at our Gummidipoondi facility using precisely sized wood chips bonded with synthetic resin and pressed under controlled pressure and temperature. This advanced process makes them denser and more uniform than traditional plywood or solid wood.
Certified with IS:3087, they meet the highest standards of quality and reliability. Their surface is treated with Activated Nanoparticles, ensuring a 99.99% virus-safe environment.
Combining durability, versatility, and aesthetics, Sharon Particle Boards are an ideal choice for applications ranging from furniture to interior solutions.
Ideal for furniture, interiors, and hassle-free installations.
| Test Properties | Specification as per IS:3087:2005 | Thickness | ||
|---|---|---|---|---|
| 9 mm | 18 mm | 25 mm | ||
|
Density (Kg/m³) (Variation +/-10%) |
500 – 900 | 690 | 650 | 630 |
| Moisture Content | 5% – 15% | 6.5% | 6.5% | 7% |
|
Modulus of Elasticity (MoE) (N/mm2) Avg. Min. Ind. |
72000
1800
|
2400
2000
|
2350
2000
|
2250
2000
|
|
Modulus of Rupture (MoR) (N/mm2) Avg. Min. Ind. |
11
10
|
13.44
13
|
13.11
12
|
12.72
12
|
|
Tensile Strength (N/mm2) Upto 20 mm thick Above 20 mm thick |
0.3
|
0.40
|
0.36
|
0.34
|
|
Maximum Linear Expansion Length Width |
0.50%
0.50%
|
0.15%
0.15%
|
0.17%
0.17%
|
0.17%
0.17%
|
| Thickness Swelling, 2 hrs. | 12% | 8% | 8% | 8% |
|
Maximum Water Absorption After 2 hrs. After 24 hrs. |
40%
80%
|
25%
50%
|
25%
50%
|
25%
50%
|
|
Screw Withdrawal (N) Face Side Edge(for thick > 12 mm) |
1250
700
|
1400
NA
|
1400
900
|
1350
900
|
| STANDARD SIZES (ft) |
9’ × 6’
|
8’ × 6’
|
6’ × 4’
|
9’ × 3’
|
8’ × 3’
|
6’ × 3’
|
| STANDARD THICKNESS (mm) |
9
|
11
|
12
|
15
|
17
|
18
|
25
|
